Rows and Row Spacing |
| Number Of Rows | 12 | 12 | 12 | 16 |
| Row Spacing | 36, 38 in. | 76.2 cm
30 in. | 12-row: 96.5 or 101.6 cm
38 or 40 in. | 76.2 cm
30 in. |
| Row Spacing | 91.4, 96.5 cm | 76.2 cm
30 in. | 12-row: 96.5 or 101.6 cm
38 or 40 in. | 76.2 cm
30 in. |
Frame |
| Frame Fold Configuration | Stack-folding | Stack-folding | Stack-folding | Stack-folding |
| Frame Flexibility - Up | 10 degree (angle) | | | |
| Frame Flexibility - Down | 7 degree (angle) | | | |
Lift System |
| Type | Integral only | Integral or semi-integral | Semi-integral only | Integral or semi-integral |
Tires |
| Base | 12.5L-15SL 20 ply implement: 303 kPa 3.0 bar 44 psi; 7.60-15 8 ply implement: 359 kPa 3.6 bar 52 psi; 7.6-15 6 ply - traction: 276 kPa 2.8 bar 40 psi | | | |
Row Units |
| Type | ExactEmerge™ row units or MaxEmerge™ 5e row units | Integral or semi-integral | Semi-integral only | Integral or semi-integral |
| Opener | Tru-Vee double disk | Tru-Vee Double Disk | Tru-Vee double disk | Tru-Vee double disk |
| Row Unit Seed Hoppers | Mini-hoppers | Mini-Hoppers: MaxEmerge 5e: 56.4 or 105.7 L
1.6 or 3.0 bu
ExactEmerge: 95.1 L
2.7 bu | Mini-hoppers | Mini-hoppers |
| Row Unit Down Force | Active pneumatic downforce or individual row hydraulic downforce (IRHD) | Adjustable heavy-duty
----
Active pneumatic downforce or individual row hydraulic downforce (IRHD) | Active pneumatic downforce or individual row hydraulic downforce (IRHD) | Active pneumatic downforce or individual row hydraulic downforce (IRHD) |
Seed Meters |
| Base Seed Meter | Vacuum | | | |
| CCS Seed Capacity | 55 bu | | | |
| CCS Seed Capacity | 1938 L | | | |
Drive System |
| Base | Electric drive: EPTO only: 56 V | | | |
Seed Monitor System |
| Base | SeedStar™ 4HP electronic system | | | |
Dimensions |
| Transport Width (Without Markers) | 22, 23.17 ft | | | |
| Transport Width (Without Markers) | 6.7, 7.06 m | | | |
| Transport Height | 13.42, 13.83 ft | | 12-row 96.5 cm (38 in.): 4.2 m
13.83 ft
12 row 101.6 cm (40 in.): 4.2 m | 16 row 101.6 cm (40 in.): 6.68 m
21.92 ft |
| Transport Height | 4.1, 4.2 m | | 12-row 96.5 cm (38 in.): 4.2 m
13.83 ft
12 row 101.6 cm (40 in.): 4.2 m | 16 row 101.6 cm (40 in.): 6.68 m
21.92 ft |
| Transport Underframe Clearance | 13.2 ft | | On 8000 Series tractors with 18.4-42 tires: 4 m
13.2 ft | On 8000 Series tractors with 18.4-42 tires: 4.22 m
13.8 ft |
| Transport Underframe Clearance | 4 m | | On 8000 Series tractors with 18.4-42 tires: 4 m
13.2 ft | On 8000 Series tractors with 18.4-42 tires: 4.22 m
13.8 ft |
