Backhoe |
| Swing Arc | 148 degree (angle) | 150 degree (angle) | 150 degree (angle) | 170 degree (angle) | 170 degree (angle) | 180 degree (angle) | 170 degree (angle) | 180 degree (angle) |
| Bucket Rotation | 176 degree (angle) | 180 degree (angle) | 180 degree (angle) | 180 degree (angle) | 180 degree (angle) | 180 degree (angle) | 180 degree (angle) | 180 degree (angle) |
| Boom Lift Capacity | 137 kg | 129 kg
285 lb | 116 kg
256 lb | 595 lb
270 kg | 820 lb
372 kg | 372 kg
820 lb | 820 lb
372 kg | 905 lb |
| Boom Lift Capacity | 302 lb. | 129 kg
285 lb | 116 kg
256 lb | 595 lb
270 kg | 820 lb
372 kg | 372 kg
820 lb | 820 lb
372 kg | 905 lb |
| SAE Dipperstick Digging Force | 7015 N | 5280 N
538 kg
1187 lb | 6681 N
1502 lb | 2041 lb
9078 N | 2449 lb
10893 N | 10830 N
2435 lb | 2449 lb
10893 N | 3065 lb |
| SAE Dipperstick Digging Force | 1577 lbf | 5280 N
538 kg
1187 lb | 6681 N
1502 lb | 2041 lb
9078 N | 2449 lb
10893 N | 10830 N
2435 lb | 2449 lb
10893 N | 3065 lb |
| SAE Bucket Digging Force | 11975 N | 9056 N
924 kg
2036 lb | 11,005 N
2474 lb | 3063 lb
13624 N | 3752 lb
16689 N | 16590 N
3730 lb | 3752 lb
16689 N | 5532 lb |
| SAE Bucket Digging Force | 2692 lbf | 9056 N
924 kg
2036 lb | 11,005 N
2474 lb | 3063 lb
13624 N | 3752 lb
16689 N | 16590 N
3730 lb | 3752 lb
16689 N | 5532 lb |
| Bucket Control Main Relief Valve Pressure | 172.4 kPa | | 2370 psi | 2250 psi
17580 kPa | 2250 psi
17580 kPa | 17580 kPa
2250 psi | 2250 psi
17580 kPa | |
| Bucket Control Main Relief Valve Pressure | 2500 psi | | 2370 psi | 2250 psi
17580 kPa | 2250 psi
17580 kPa | 17580 kPa
2250 psi | 2250 psi
17580 kPa | |
Dimensions |
| Digging Depth | 2.08 m | 1.9 m
6 ft, 2 in. | 2.13 m
7 ft, 0 in. | 94 in.
2.38 m | 103 in.
2.61 m | 2.67 m
8 ft, 9 in. | 102 in.
2.59 m | 9 ft, 4 in. |
| Digging Depth | 6 ft | 1.9 m
6 ft, 2 in. | 2.13 m
7 ft, 0 in. | 94 in.
2.38 m | 103 in.
2.61 m | 2.67 m
8 ft, 9 in. | 102 in.
2.59 m | 9 ft, 4 in. |
| Loading Height (Bucket at 60 Degrees) | 1.8 m | 1.5 m
5 ft | 1.74 m
6 ft, 1 in. | 68 in.
1.72 m | 78 in.
1.98 m | 2.24 m
7 ft, 4 in. | 79 in.
2.00 m | 8 ft
2.4 m
2 in. |
| Loading Height (Bucket at 60 Degrees) | 5 ft | 1.5 m
5 ft | 1.74 m
6 ft, 1 in. | 68 in.
1.72 m | 78 in.
1.98 m | 2.24 m
7 ft, 4 in. | 79 in.
2.00 m | 8 ft
2.4 m
2 in. |
| Reach From Center Line of Swing Pivot | 3 m | 2.6 m
8 ft, 8 in. | 3.0 m
9 ft, 9 in. | 129 in.
3.27 m | 140 in.
3.55 m | 3.61 m
11 ft, 10 in. | 140 in.
3.55 m | 12 ft
3.9 m
11 in. |
| Reach From Center Line of Swing Pivot | 9 ft | 2.6 m
8 ft, 8 in. | 3.0 m
9 ft, 9 in. | 129 in.
3.27 m | 140 in.
3.55 m | 3.61 m
11 ft, 10 in. | 140 in.
3.55 m | 12 ft
3.9 m
11 in. |
| Transport Height | 2 m | 1.7 m
6 ft, 6 in. | 1.92 m
6 ft, 3 in. | 85 in.
2.16 m | 91 in.
2.31 m | 2.29 m
7 ft, 6 in. | 92 in.
2.33 m | 8 ft
2.6 m
8 in. |
| Transport Height | 6 ft | 1.7 m
6 ft, 6 in. | 1.92 m
6 ft, 3 in. | 85 in.
2.16 m | 91 in.
2.31 m | 2.29 m
7 ft, 6 in. | 92 in.
2.33 m | 8 ft
2.6 m
8 in. |
| Loading Reach (Bucket at 60 Degrees) | 1.17 m | 0.8 m
2 ft, 9 in. | 1.13 m
3 ft, 7 in. | 44 in.
1.11 m | 51 in.
1.11 m | 1.17 m
3 ft, 10 in. | 51 in.
1.29 m | 5 ft
1.5 m
1 in. |
| Loading Reach (Bucket at 60 Degrees) | 3 ft | 0.8 m
2 ft, 9 in. | 1.13 m
3 ft, 7 in. | 44 in.
1.11 m | 51 in.
1.11 m | 1.17 m
3 ft, 10 in. | 51 in.
1.29 m | 5 ft
1.5 m
1 in. |
| Transport Overhang | 1.1 m | 0.9 m
3 ft, 1 in. | 1.1 m
3 ft, 6 in. | 48 in.
1.22 m | 48 in.
1.29 m | 1.32 m
4 ft, 4 in. | 53 in.
1.34 m | 5 ft
1.5 m
1 in. |
| Transport Overhang | 3 ft | 0.9 m
3 ft, 1 in. | 1.1 m
3 ft, 6 in. | 48 in.
1.22 m | 48 in.
1.29 m | 1.32 m
4 ft, 4 in. | 53 in.
1.34 m | 5 ft
1.5 m
1 in. |
| Undercut | 43 cm | 0.4 m
1 ft, 5 in. | 43 cm
17 in. | 17.5 in.
0.44 m | 19 in.
.48 m | 0.56 m
1 ft, 10 in. | 19 in.
0.48 m | 1 ft
335 mm
10 in. |
| Undercut | 17 in. | 0.4 m
1 ft, 5 in. | 43 cm
17 in. | 17.5 in.
0.44 m | 19 in.
.48 m | 0.56 m
1 ft, 10 in. | 19 in.
0.48 m | 1 ft
335 mm
10 in. |
| Stabilizer Spread Width - Up | 1.17 m | | | | | | | |
| Stabilizer Spread Width - Up | 4 ft | | | | | | | |
| Stabilizer Spread Width - Down | 1.9 m | | | | | | | |
| Stabilizer Spread Width - Down | 6 ft | | | | | | | |
Weight |
| Weight With 0.4-m (16-in.) Bucket | 350 kg | | | | | | | |
| Weight With 0.4-m (16-in.) Bucket | 773 lb. | | | | | | | |
Bucket |
| Bucket Widths | 20.3 cm | 0.2 m (8 in.)
0.3 m (12 in.)
0.4 m (16 in.) | 203.2 mm (8 in.)
304.8 mm (12 in.)
406.4 mm (16 in.) | 9 in. (228 mm)
12 in. (305 mm)
16 in. (406 mm)
18 in. heavy duty (457 mm)
20 in. (508 mm)
24 in. (610 mm) | 9 in. (228 mm)
12 in. (305 mm)
16 in. (406 mm)
18 in heavy-duty (457 mm)
20 in. (508 mm)
24 in. (610 mm) | 305 mm (12 in.)
457 mm (18 in.)
610 mm (24 in.)
914 mm (36 in.) | 9 in. (228 mm)
12 in. (305 mm)
16 in. (406 mm)
18 in heavy-duty (457 mm)
20 in. (508 mm)
24 in. (610 mm) | 14 in.
18 in.
24 in.
36 in.
40 in. |
| Bucket Widths | 8 in. | 0.2 m (8 in.)
0.3 m (12 in.)
0.4 m (16 in.) | 203.2 mm (8 in.)
304.8 mm (12 in.)
406.4 mm (16 in.) | 9 in. (228 mm)
12 in. (305 mm)
16 in. (406 mm)
18 in. heavy duty (457 mm)
20 in. (508 mm)
24 in. (610 mm) | 9 in. (228 mm)
12 in. (305 mm)
16 in. (406 mm)
18 in heavy-duty (457 mm)
20 in. (508 mm)
24 in. (610 mm) | 305 mm (12 in.)
457 mm (18 in.)
610 mm (24 in.)
914 mm (36 in.) | 9 in. (228 mm)
12 in. (305 mm)
16 in. (406 mm)
18 in heavy-duty (457 mm)
20 in. (508 mm)
24 in. (610 mm) | 14 in.
18 in.
24 in.
36 in.
40 in. |
| SAE Struck Capacity | 20.3 cm (8 in.) - 0.012 m3 - 0.42 cu ft cu ft; 30.5 cm (12 in.) - 0.019 m3 - 0.66 cu ft; 40.6 cm (16 in.) - 0.25 m3 - 0.9 cu ft | | | | | | | |
| Heaped Capacity | 20.3 cm (8 in.) - 0.013 m3 - 0.46 cu ft; 30.5 cm (12 in.) - 0.022 m3 - 0.76 cu ft; 40.6 cm (16 in.) - 0.03 m3 - 1.06 cu ft | | | | | | | |
| Shipping Weight | 20.3 cm (8 in.) - 40 lb (18.1 kg); 30.5 cm (12 in.) - 50 lb (22.7 kg); 40.6 cm (16 in.) - 60 lb (27.2 kg) | | | | | | | |
